AUTO GBDA-180 Compost Degradation plastics test equipment

AUTO GBDA-180 The Compost Degradation Tester is based on the gravimetric method for measuring carbon dioxide emissions. It is a professional use of small reactors to determine the final biodegradability of test materials. It is suitable for the biodegradability analysis of degradable plastics and bio-based materials such as lunch box garbage, waste ground film, plastics containing plasticizers and pigment additives, etc.


  • Item NO.:

    AUTO GBDA-180
Inquiry now
Product Detail


Executive Standard

ISO14855-1ASTM D5338ASTM D6400JIS K 6953 GB22047ISO 17556-2012, GB/T19277.1


Testing Principle

The test material of this method is a mixture of inoculum of decomposed compost and inert materials (such as sea sand and vermiculite). By controlling the humidity, oxygen permeability and temperature of the compost container, the sample to be analyzed in the reaction chamber is under the action of microorganisms. The biodegradation reaction is carried out through respiration, and oxygen becomes carbon dioxide and is discharged through respiration. The amount of carbon dioxide released is measured by weighing the absorption device equipped with soda lime and sodium talc, and the decomposition rate is calculated by regular measurement.



Technical parameter

Item

Technical Parameter

Temperature Control Range

Room Temperature 80°C

Temperature Control Accuracy

±0.5°C

Flow Control Range

0.01~1L/min

Flow Control Rate Accuracy

±1.0%FS

Flow Detection Range

0.012L/min

Flow Detection Accuracy

±1.0%FS

Carbon Dioxide Detection Range

010000ppm

Carbon Dioxide Detection Accuracy

0-3000 ppm, ±40 ppm. 3000-10000 ppm, ±2%

Oxygen Detection Range

025%

Oxygen Detection Accuracy

±1%FS

Test Chambers

18 chambers

Air Source Connection

φ8

Air Source Pressure

0.20.8 MPa

Test Cavity Volume

3.5L

Dimensions

3600mm*810mm*1930mm

Weight

1100kg

Power

3000W

Power Supply

AC 220V, 50Hz




Features

Precise control of experimental conditions

  • 360℃ air bath temperature control, intelligent PID module algorithm can accurately control the temperature required for the reaction.
  • Intelligent detection of humidity, automatic humidification of the external water tank and condensate return technology to ensure that the standard requirements for the water content of the inoculum are met within the test cycle.


Technological advancement
  • Intelligent air tightness monitoring, equipped with high-precision brand flowmeters, real-time monitoring system sealing performance, providing suspected leakage alarm function, ensuring that each composting container can maintain sufficient aeration conditions during the test.
  • Support accidental power failure during the test period, and the test function will continue to be restored after incoming calls.
  • The channels can be freely combined, and the blank, reference, and sample modes can be freely set for independent testing.
  • Real-time display of carbon dioxide quality curve and biodegradation rate curve.
  • Support remote monitoring of the experimental process through mobile phones, ipads, and PCs.


Result validity analysis

  • The software contains a result validity judgment module, which can display the biodegradation rate of the reference material after 45 days, the carbon dioxide (mg) produced by the blank container within 10 days before the experiment (mg)/the volatile solids of the inoculum (g), and the biodegradation rate of 18 channels Relative deviation.
  • The report template contains parameters such as the average carbon dioxide value of the blank group, theoretical carbon dioxide, generated carbon dioxide, biological decomposition rate, relative decomposition rate and time.


Personalized customization

  • The tail gas analysis module can be customized to meet different scientific research needs, such as methane, ammonia, nitrogen dioxide, hydrogen sulfide, sulfur dioxide, odor, VOC and other gas characteristic parameters.
  • Support 12/18/24/30 station customization, support data mean mode customization.
