Applied to:
1) Plastic film, composite film, aluminum foil, aluminized film, etc;
2) Sheet, panel, rubber, ceramics, etc;
3) Packaging containers, such as: glass, bottle, cans, boxes, etc;
4) Expanding application: solar panel, LCD film, medical patch, etc.
Widely used in quality inspection organizations, drug control institutions, research institutes, packaging, thin film, food companies, pharmaceutical enterprises, personal care industry, electronics industry and so on.
Standard
ISO15106-3, ASTM E398, GB/T 21529, DIN 53122-2, YBB00092003
Accurate and reliable data
With The State Certificate for Gradation of the certified Reference Materials and Licence for Manufacturing Measuring Instruments of the state Reference Material（GBW(E)130543/4）of Water Vapor Permeability Analyzer approved and issued by General Administration of Quality Supervision, Inspection and Quarantine of the P.R.C. Adopting state reference materials to calibrate and verify the instruments, ensure the accuracy, universality and authority of the test data.
Simple operation
Professional software with simple interface, easy to use and convenient to set test process.
Fully-auto operation, one-button test, judge and stop automatically.
Mainframe configure with color touch screen, can observe temperature, humidity and transmission without external computer.
Professional test report can be automatically generated and exported in PDF format.
Advanced technology
Humidity control: Dual gas flow method (dry gas and humid gas), high precision (1%RH) and constant humidity.
Supports electronic signature, online report submission, auditing function
High efficiency
With three different test modes of high, medium and lower barriers, can test films with different barrier property.
Measurement precise up to 0.001 g/m2·24h, can test high barrier materials, such as aluminum foil.
Authority management & data trace
The software is designed according to the requirements of the new GMP Appendix computerized system.
Need a user name and password to log in to the workstation, and ensure the safety and effectiveness of account and experiment data.
Users can be classified into different levels of system administrator, instrument administrator, auditor and operator.
The system administrator can adjust the permissions of various levels, for example, increase and decrease system control items of any level.
Have audit and trace functions (test tracking, log tracking), every data change is recorded, ensure the security and integrity of test data.
Reliable and easy-maintenance instrument
Imported infrared sensor, with high precise and good performance, can work for a long time.
Sensor over-range automatic protection, prevent damaging important sensors while instrument failure.
Functional modular design, easy to maintain.
Specification
| Item | Technical Parameters |
|---|---|
| Testing Range | 0.001 - 40 g/(m²·24h) (Films and Sheets) |
| Testing Precision | 0.0001 g/(m²·24h) (Films and Sheets) |
| Temperature Control Range | 15 - 45℃ |
| Temperature Control Precision | ±0.1℃ |
| Humidity Control Range | (5 - 90)%RH |
| Humidity Control Precision | ±1%RH |
| Permeation Area | 50.24 cm² |
| Specimen Size | Φ100 mm |
| Specimen Thickness | ≤3mm |
| Number of Specimens | 3 pieces |
| Carrier Gas | 99.999% Nitrogen (Provided by the User) |
| Carrier Gas Pressure | ≥0.1MPa |
| Carrier Gas Flow Rate | 0 - 100 mL/min |
| Gas Source Interface | 1/8-inch Metal Tube |
| Overall Dimensions | 670×550×400mm |
| Weight | 57.1kg |
| Power | 750W |
| Power Supply | AC 220V, 50Hz (110V power supply is available as an additional option) |
