Moisture vapor permeability analyzer using infrared method is to test the water vapor transmission rate (WVTR) of films or sheets materials for food and pharmaceutical industries.

  GF-2700XB Dual-channel Linear Oblique Tube Sealing Machine Product Introduction The fully automatic dual-channel linear oblique tube sealing machine is professionally used for automatic tube sleeving and heat sealing of straws and bags. It is suitable for straws of various calibers, lengths and models. It is the preferred automated equipment for packaging bags such as laundry detergent spout oblique bags, beverage & juice oblique spout bags, engine oil & edible oil oblique spout bags, and outdoor foldable water oblique bags. Technical Parameters Overall Dimension Main unit: 4790mm×4800mm×1800mm; Collecting conveyor: 2015mm×510mm×930mm (L × W × H) Sealing Type Stand-up bag, three-side sealed bag, gusset bag, special-shaped bag Material Type Bag: Inner PE, Inner PP materialSpout: PE, PP material Product Specification Oblique sealed bag: Length 150~350 mm, Width 130~250 mm, Sealing length 60~120 mmCenter sealed bag: Length 150~350 mm, Width 130~200 mm, Sealing length 60~120 mmSpout caliber: 8.5 mm (standard), 10 mm, 14 mm, 16 mm, etc. Working Speed 80~90 pcs/min for dual channel; 40~45 pcs/min for single channel Positioning Accuracy ≤±1 mm Sealing Cutter Group Single side: 7 groups in total (4 heat sealing groups, 1 cooling group, 2 preheating groups)Two sides total 14 groups (8 heat sealing groups, 2 cooling groups, 4 preheating groups) Temperature Control Module & Heating Temperature 4 sets (2 sets of 4-channel modules + 2 sets of 8-channel modules), accuracy ±0.1℃; Heating temperature range: 0~300℃ Power Supply 380V/50Hz, rated power approx. 17KW, current approx. 40A Air Source 0.5~0.7MPa, 1200L/min Equipment Weight Approx. 4700 kg Product Features Adopts dual-channel mode, fully automatic operation of bag separating, angle cutting, tube loading and heat sealing procedures; Equipped with PLC control and intelligent parameter setting, parameters can be quickly set according to different bag types and straws, simple operation; Adopts imported temperature control modules and pneumatic components such as SMC, Festo and Airtac with reliable quality; Designed with step-by-step heating and final cooling sealing process to achieve excellent sealing effect; Automatic fault detection, alarm, stop, diagnosis and fault location display; Light weight, small floor space and stable performance; Main components are made of aluminum alloy and stainless steel, complying with food and pharmaceutical GMP environmental hygiene requirements. System Composition The equipment adopts dual-channel design, consisting of bag feeding system, tube feeding system, cutting mechanism, heat sealing system, bag collecting system, control system and machine base; The bag feeding system is composed of bag separating mechanism, positioning mechanism and handling mechanism; the separating mechanism separates finished bags one by one, the handling mechanism transports bags, and the positioning mechanism corrects position; The tube feeding system includes vibration plate, linear vibration feeding and rotary tube loading mechanism; automatic detection and start-stop control during feeding; The heat sealing system includes heat sealing and cooling, with 5 sets of heat sealing knives and 1 set of cooling knives; customized heat sealing and cooling knives of different specifications are available to adapt to straw sealing of various sizes; Each set of sealing knives has independent temperature control, which can set temperature and operate debugging independently; The bag collecting system conveys at constant speed and arranges bags automatically, convenient for product observation and inspection; The operation interface real-time displays working status such as production speed, finished quantity, shift output, date and temperature. Application Fields Laundry Detergent Stand-up Bag Seasoning Stand-up Bag Juice Stand-up Bag Foldable Water Bag

Application Use for test the light transmittance and haze degree of all transparent and semi-transparent parallel plane samples (plastic plate, sheets etc), and turbidity or clarity of liquid samples (water, drinks etc), used in the industries of plastics, membrane, coatings and paints, printing ink, research institute and so on.

Paper Air Permeability Tester tests the air permeability, air permeability resistance of paper and cardboard. It adopts the testing principle of differential pressure method and combines Gurley method, Schauer method and Bengtsen method.

Film Heat Shrinkage Tester tests various heat shrinkage properties for the film according to the principle of air heating (air bath). Suitable for heat shrinkable films which produced with polyethylene, ethylene copolymers and their mixtures, such as beverage labels, bottled bundle packaging, sausage shrinkage packaging, outer film of daily chemical products, outer film of cigarette boxes, etc. It is a device that can accurately and quantitatively measure the thermal shrinkage force, cold shrinkage force, shrinkage rate, shrinkage time and other properties of plastic films during thermal shrinkage. The test results have a variety of data, which can evaluate the heat shrinkage performance of the film from different aspects, contribute to the research and development of heat shrinkable films of different materials, ensure the stability of heat shrinkable films performance of various materials, and meet the requirements of various heat shrinkable films in various industries. GBPI checks the key thermal shrinkage properties of film products for you. The traditional oven or oil bath equipment only detects the heat shrinkage rate of the heat shrinkable film, and the test results are relatively limited. Our Film Heat Shrinkage Tester GBK-D1 can evaluate the thermal shrinkage performance of films from various data. It is easy to operate, environmentally friendly, with high data accuracy and more comprehensive test results to meet your requirements.

Full-Automatic Overall Migration Tester AUTO ZF900 has an integrated system design of water bath evaporation, heating and drying, drying and cooling, and constant temperature weighing. It is suitable for testing the total migration (non-volatile matter, evaporation residue) and other items in the fields of purified water, pharmaceutical packaging materials, food packaging, cigarette tipping paper and chemical reagents. It can also be applied to the water content, loss on drying and other items of solid samples, and the total dissolved solids content test in water quality testing.

  GBL-H2 Universal Single Column Electronic Tensile Tester Product Introduction Developed by R&D team of Guangzhou Biaoji Packaging Equipment Co., Ltd., GBL-H2 universal single column electronic tensile tester complies with GB, ASTM and other relevant standards and market demands. Equipped with high-precision sensors, it features high force measurement accuracy, stable loading and long service life. The LCD screen with professional software displays real-time test curves and data, and supports test report query for easy operation. With fully automatic control unit, it is equipped with complete safety protection functions including limit protection, overload protection and emergency stop. This tester is used for tensile, peeling, heat seal, tearing, puncture and other mechanical property tests of metallic and non-metallic materials. It meets the technical requirements of national supervision departments, and is widely applied in quality control of plastic film, food and pharmaceutical enterprises, as well as scientific research and teaching experiments of testing institutions and schools. Test Principle Fix the prepared specimen between two clamps. Start the instrument to make the two clamps move relatively. The force sensor on the moving clamp collects force changes during the test, and the built-in displacement sensor records displacement changes. Finally, the mechanical indicators such as tensile strength, peeling strength, heat seal performance and tearing strength of the specimen are calculated. Compliance Standards GB 8808, GB 13022, GB/T 1040, GB 4850, GB/T 7753, GB/T 7754, GB/T 453, GB/T 17200, GB/T 16578.1, QB/T 1130, GB/T 2791, GB/T 2790, GB/T 2792, GB/T 7122, GB/T 10004, GB/T 17590, JJG 139, GB/T 6344, GB 10808, YBB 00112003, YBB 00102003, YBB 00132002, YBB 00202004, ASTM D828, ASTM E4, ASTM D882, ASTM D1938, ASTM D3330, ASTM F904, JIS P8113, QB/T 2358 Technical Parameters Force Measuring Range 0~300 N (Optional: 0~500 N) Force Measuring Accuracy Within ±0.5 %FS (Class 0.5) Test Speed 0~500 mm/min (Stepless speed regulation) Displacement Accuracy Within ±0.5% Effective Test Width 30 mm (Customizable: 50 mm, 60 mm) Effective Test Stroke 750 mm (Customizable: 1000 mm, 1200 mm) Overall Dimension L×W×H：600 mm×500 mm×1300 mm Weight 65 kg Power Supply AC 220 V，50 Hz Product Features Elegant and portable desktop single-column structure, comfortable for sitting operation. Supports tensile, peeling, heat seal, tearing, puncture and other tests; multiple adjustable parameters. High sampling rate (100 times/second) ensures accurate test data. Three-level safety protection with emergency stop switch. Adopts imported core components for high precision and long service life. LCD screen displays real-time data and working status. Intelligent operating system supports user management, authority management and audit trail, complying with GMP computerized system requirements. It can work independently or connect with computer for online testing, and the built-in printer outputs data in real time. Optional laboratory intelligent IoT platform, realizing data management and remote fault diagnosis.

1 Function Ozone in the atmosphere is very little, while it’s a major factor in rubber cracking, the product simulate and enhance atmospheric ozone condition to study the role of ozone on the rubber, and to rapid identificate and evaluate rubber resistance for ozone aging and anti-ozone agent protection. According to“GB / T7762-2003 Test Method for Static Tensile Test of Ozone Resistance Cured Rubber or Thermoplastic Rubber”,“GB / T2951.21-2008 General Test Method for Insulation and Sheathing Material of Cable”,“GB / T 11206-2009 Rubber Aging test surface cracking method”, and other relevant standards of the test method. 2.1 Structure  All-in-one machine 2.2 Material a) Inner chamber: SUS304 stainless steel plate b) External chamber: SUS304 stainless steel plate or baking finish. Insulation: rigid polyurethane foam + aluminum insulation cotton with double protection. 2.3 Machine door a) Single door, open from left. b) Window frame / door frame with two silicone rubber seal and anti-condensation heating device. c)With observation window (W220xH250mm), lights above the window and door.  2.4 Requirements for sample holder (for dynamic-type only)       a)At both ends of the sample to be fixed with a clamp under the required elongation, the longitudinal direction of the specimen shall be substantially parallel to the direction of air flow when in contact with ozonized air. b) Clamps shall be made of a material (eg aluminum) which does not readily decompose ozone. c) Allow the sample to rotate at a speed between (20 ^ -25) mm / s, in a plane perpendicular to the dry gas flow, with each sample moving continuously along the same path. d) The time of one revolution of the same specimen is (8 ^ -12) min. The scanning area of the specimen shall be at least 40% of the effective area of the test chamber. Specimen preparation shall conform to the provisions of GB / T 9865.1. The test specimen is preferably cut from the new test piece and, if desired, may be cut from the finished product. At least 3 specimens shall be required for per test condition. The standard length of the specimen is not less than 10mm, and thickness not less than 0.2mm. The length of specimen between the two ends of the clamp before drawing is not less than 40mm. 3 Control panel a) Controller display b) Power switch c) Fault alarm d)Wavelength switch e)light switch button 4 Enclosure configuration a) With a stainless steel SUS # 304 shelf turntable b) One φ50mm lead hole:, and with a hole cover and silicone rubber plug. c) Move casters 4 pcs d) Horizontal mounting brackets 4 pcs e) There is a drainage hole in the back of the machine to facilitate the drainage of condensate; (8mm in diameter) Three-phase five-wire cable (four-core cable + protective grounding wire) 1 pc, (three meters long).



    LIMS Intelligent Laboratory Management System One-stop All-round Lab Information Management About GBPI & LIMS Overview Founded 2002, GBPI supplies packaging test instruments & lab solutions, with CNAS testing center serving global food/pharma/material labs. Self-developed LIMS eliminates manual lab defects, auto-collects data, full traceability for Man/Machine/Material/Method/Environment, user-friendly all-in-one lab management. LIMS System Homepage All-in-One Lab Digital Ecosystem LIMS/SDMS/LES/ELN PLM/CRM/Warehouse IoT & Data Analysis Dashboard & Mobile App Modular unified data platform, auto workflow, full traceability, cuts manual bottlenecks & meets multi-site compliance demands. Core Lab Capabilities ●Resource scheduling & test plan management ●Sample & document centralized archive ●Auto generate compliant custom reports ●Auto data acquisition & trend analysis ●Barcode sample full lifecycle traceability Platform Supported Operations ●Abnormal data alert & intelligent review ●Auto result vs specification comparison ●Auditable electronic record management ●Personnel/equipment/sample integrated control ●Data analytics & full compliance audit trail Platform Core Strengths All core lab modules integrated, no third-party docking cost, fast deployment, data analytics & full lifecycle QC for standardized lab management. Rapid Industry Deployment Pre-built industry templates, fully customizable lab workflows. Intelligent Data Analysis Visual dashboard delivers real-time data for precise decisions. Full Lifecycle Management Full QC covering sample entry to final report output. Compliance & Traceability Built-in audit trail & e-signature to meet regulatory standards. Core Competitive Advantages Web access,no install,multi-industry fit Auto bilingual reports,QR paperless share PC&mobile remote equipment schedule Barcode sample register & storage visualization IoT remote virtual lab monitoring Smart resource allocation & third-party test support Standard Business Workflow Sample Login ➡️ Sampling & Receipt ➡️ Resource Planning ➡️ Data Analysis ➡️ Review & Approval ➡️ Report Output Multi-Module Collaborative System Business & Contract Management Order tracking,digital contract & intelligent quotation Sample & Equipment Management Full sample traceability,remote equipment monitoring Testing & Report Management Auto test records,custom reports & real-time data share Quality & Security Management QC control,role permission & full audit management   Full-Lifecycle Professional Service One-stop customized LIMS service including consultation,development,deployment & after-sales support,tailored for all lab scales & industries. 1 Planning Kickoff & training 2 Development Custom configuration 3 Testing Function verification 4 Preparation Audit & user training 5 Deployment Online launch & acceptance Pharma & Biotech Custom Solution Compliant LIMS for pharma/biotech labs, meets FDA audit standards, full data traceability & multi-site collaborative quality control. Integrated Platform Management Unified R&D/test/production data archiving & monitoring. Professional Lab Workflow Full control of instrument,inventory,testing & reporting. Strict Compliance Guarantee Built-in audit workflow to pass pharmaceutical regulatory inspection.

Product Introduction The LC-3S manual precision sample cutter can be used for precision sample cutting in tensile testing of materials such as copper-aluminum foil, battery separators in the new energy industry, various plastic films, paper, paper-plastic composites, and metals. This product is easy to operate, safe, reliable, and durable. The cut samples are smooth without burrs, enabling precise cutting of samples and effectively avoiding measurement errors caused by poor sample cutting.   Product Features Item Technical Parameters Material Thickness ≤1mm Cutting Specification 15mm × 220mm (customizable) Equipment Size 250mm × 550mm × 400mm Weight 9kg   Product Features ✦ The sample cutter has a compact design, is sturdy and durable, easy to operate, and efficient.✦ The cutting blade is made of high-speed tool steel, with a high-hardness edge that is sharp and durable. The cut samples are undamaged with smooth edges without burrs.✦ The width of the cut sample is 15mm, with high cutting precision, fully meeting standard requirements. It also supports customization of different sample cutting widths.✦ Both sides of the blade are designed with safety protection barriers, ensuring safe and reliable sample cutting process.
