GBB-F1 Heat Seal Tester is to test the temperature, pressure, and time for heat sealing of various film materials. It is applied to quality inspection organizations, drug control institutions, research institutes, packaging, thin film, food companies, pharmaceutical enterprises, personal care industry and so on.

OTH-150DJ is used to test the performance of materials in various environments and test the heat resistance, cold resistance, dry resistance and humidity resistance of various materials. It is suitable for quality testing of products such as electronics, electrical appliances, mobile phones, communications, instruments, vehicles, plastic products, metals, food, chemicals, building materials, medical care, and aerospace.

The Compression Tester GBN200A is professionally used to test the pressure resistance and burst resistance of various packaging bags. It can set the pressure and measure the deformation; set the deformation and measure the pressure resistance. It is an ideal testing equipment for quality inspection, drug inspection, scientific research, packaging, film, food, medicine, daily chemical and other industries.

Heat Seal Analyzer widely used in industries of plastic films, food, pharmaceuticals, inspection agency, research institute and so on,it is to test the temperature, pressure, and time for heat sealing of various film materials.

This machine is used to test the compression, deformation resistance and stacking of corrugated carton, honeycomb board box and so on.



The HP-D1 Automatic Torque Tester HP-D1 is innovated to test cap torque for detecting sealing performance of packaging containers, such as plastic bottles, liquid boxes, cans, etc.

Product Brief The N600C Carbon Paper Air Permeability Rate Tester is designed and developed in accordance with GB/T 20042.7-2014. Adopting the differential pressure method as its testing principle, it is professionally used for measuring the air permeability rate of various types of carbon paper for proton exchange membrane fuel cells (PEMFC). Testing Principle Based on the differential pressure method, the sample is placed between two fixtures, forming a constant differential pressure on both sides of the sample. Driven by the differential pressure, gas flows from the high-pressure side through the sample to the low-pressure side. The air permeability rate of the carbon paper is calculated based on the transmission flow rate, sample thickness, test area, and test differential pressure. Executed Standards GB/T 20042.7-2014 Technical Parameters Item Technical Parameters Test Range 0~200,000 mL·mm/(cm²·h·mmHg)0~14,701 mL·mm/(cm²·hr·mmAq) Resolution 0.1 mL·mm/(cm²·h·mmHg)0.1 mL·mm/(cm²·hr·mmAq) Pressure Range 0~500 Pa (other ranges available upon request) Pressure Resolution 0.1 Pa Pressure Accuracy 0.1% FS (Full Scale) Flow Range 0~50 L/min (other ranges available upon request) Flow Resolution 1 mL/min Flow Accuracy 1% FS (Full Scale) Test Area 16 cm² Instrument Dimensions 410 mm×295 mm×365 mm Power 100 W Power Supply 110~250 VAC, 50~60 Hz Product Features • The instrument's differential pressure is adjustable within the range of 0~500 Pa, with an accuracy of 0.1% FS, fully meeting the test pressure requirements of different samples;• The test range can be customized according to different sample requirements;• Arbitrary pressure adjustment, fully automatic operation, and automatic measurement and calculation of results;• Equipped with a color touch screen, no external computer required;• Built-in micro-printer for real-time printing of test reports;• The upper computer software is designed in accordance with the new GMP Appendix "Computerized Systems", supporting functions such as hierarchical permission management, audit trail, and electronic signature (optional).

product description This product is based on the test principle of cup method water vapor transmission, and is designed and manufactured according to ASTM E96, GB/T 1037 standards, and provides a wide range and high efficiency water vapor transmission rate detection for low, medium and high water vapor barrier materials. test.

  The AUTO GQ-100 Modified Atmosphere Refrigerator is meticulously engineered for storage and preservation tests of diverse fruits, vegetables, flowers, seedlings, and more. By harnessing microelectronics technology, it automatically regulates the concentrations of oxygen, nitrogen, carbon dioxide, and ethylene inside the refrigerator, along with temperature and humidity conditions, to achieve outstanding preservation effects. It is an essential and perfect equipment for microbiology, environmental protection, food production, universities, research institutions, and other relevant organizations.   Technical Parameters Project Technical Parameter Gas Measurement Range O₂: 0%–30%; CO₂: 0%–20%; C₂H₄: 0–220 ppm; Remaining gas: N₂ Gas Testing Accuracy O₂: 0.01%; CO₂: 0.01%; C₂H₄: 0.1 ppm Gas Purity Requirement Purity of O₂, CO₂, N₂, and C₂H₄ ≥ 99.9% Gas Flow Control O₂: 0–500 mL/min; CO₂: 0–500 mL/min; N₂: 0–500 mL/min Temperature Control Range -5°C–45°C Chamber Temperature Control Accuracy ±0.5°C Chamber Humidity Range Normal–95% RH Humidity Fluctuation Range ±3% RH Cooling Capacity 1 HP Chamber Humidifier Power 50 W Chamber Lighting System Power 10 W Material Colored steel plate Dimensions 889 mm × 1285 mm × 1750 mm Total Machine Power 1 KW Number/Volume of Test Chambers 1 chamber/100 L Power Supply AC 220V   Application   Fruit and vegetable storage and preservation It is suitable for the storage and preservation test of various domestic and imported fruits and vegetables.   Storage and preservation of meat and seafood It is suitable for storage and preservation test of various pork, beef, mutton and other meat and seafood products such as fish, shrimp, crab, etc.   Baked food storage and preservation It is suitable for the storage and preservation test of various bakery products such as bread, cakes and biscuits.   Storage and preservation of flowers and seedlings It is suitable for the storage and preservation test of various roses, lilies, phalaenopsis and other flowers and seedlings.   Product features Three test chambers work independently; Each chamber has its own humidity, flow and concentration of various gases, ethylene removal devices, lighting systems, sterilization systems, and drainage systems.  Built-in microcomputer system, automatic control, and automatic processing of data. Manually switch the cavity to display the temperature and humidity of each cavity, as well as the concentration of oxygen, nitrogen, carbon dioxide, ethylene, and so on.   24 inch 100,000 real color touch screen, can set the parameters of each cavity and control operations respectively; Detailed data and work status are displayed in real time.  Built-in ozone sterilization, manual button sterilization, can set the sterilization time.  Built-in ethylene catalytic removal device and gas displacement pump control ethylene concentration, fast degassing speed.  Imported high-precision sensors to detect various gas concentrations and ethylene concentrations. The sterilization system adopts ozone sterilization, the manual button for sterilization, automatic control of sterilization time, and automatic stop when the set time is reached. Temperature control: using heating wire heating, scroll compressor cooling, stable performance, low noise; PID algorithm with solid state relay control, no hard mechanical contacts, long service life, average temperature heating, constant temperature. The temperature control of each chamber adopts unified control, and the temperature of the three chambers is set manually. Humidity control: high-frequency atomization humidification, the humidification range is large, long-term humidification does not heat, does not affect the cavity temperature; Each chamber humidification system operates independently, automatically humidifies and maintains humidity after setting the humidity. The inner wall of each cavity is made of stainless steel, the special double-layer glass door, and the shell is made of special color steel plate.  Transparent windows, drainage system anti-condensation, built-in lighting, and self-entry box design.

The Coefficient of Friction Tester equipment performs tests to most of the recognised international test standards including IS0 8295 and ASTM 1894-78.

Introduction Based on the test principle of the differential pressure method, N530L is designed with reference to the GB/T 1038 standard and used to test the gas transmission rate (quantity) of film or sheet materials.
